1.5HP LEESON 1800RPM 56C DP 3PH MOTOR 110044

LEESON 110044.00 has been Superseded by E116741.00

Catalog Number:  110044.00
Model Number:  C6T17DC2
Description:  1.5HP,1800RPM,56C,DP,3PH,60HZ
Ship Weight:  30 lbs.
Volts 230   Volts 460   Volts
FL Amps 5.6   FL Amps 2.8   FL Amps
SF Amps 5.9   SF Amps 2.95   SF Amps
RPM 1800   Hertz 60
HP 1 1/2   Duty CONTINUOUS   Type TD
KW 1.12   SF 1.15   Phase 3
Frame 56C   Design B   KVA Code K
Ambient 40   Protection NOT   Therm.Prot.
Insulation Class B   Eff(75%)     PF 64
Eff(100%) 78.5   CSA Y   Bearing OPE 6203
UL Y   CE N   Bearing PE 6203
CC Number EXEMPT   Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 30 LB   Enclosure DP   Lubrication POLYREX EM
Nameplate 004002   Mounting ROUND   Rotation REV
Shaft Diam. 5/8 IN   Cust Part No.     Packaging B
      Winding T634196   Carton Label INDIVIDUAL - NOT FOR USE IN USA
      Group 3   Iris
Paint BLUE - LEESON (ENAMEL)   Hazardous Location NONE   Test Card 02
1.5HP LEESON 1800RPM 56C DP 3PH MOTOR 110044
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 110044.00
Stock # 110044
