1/2HP LEESON 1800RPM 56C TENV 24VDC EPOXY WASHDOWN MOTOR 109299.00

1/2HP LEESON 1800RPM 56C TENV 24VDC EPOXY WASHDOWN MOTOR 109299.00


Part Number:

109299.00

Model/Spec Number:

C4D18VK10

Manufacturer:

Leeson Obsolete
109299.00 LEESON 1/2HP LOW VOLTAGE PMDC WASHGUARD MOTOR is suitable for installations having battery, solar powered, or generator supplied operation and is designed for extended life in wet, high humidity applications.

Ordering Notes

This product has been discontinued with no direct replacement from the manufacturer. The functional equivalent should be reviewed for application compatibility.


Item Discontinued

Click below to request an agent review potential options.

Weight:

30 lbs

Dimensions:

11 x 20 x 11 inches

HS Code:

8501.31.0000

UPC:

691720100202

Technical Details

Application:

Epoxy Washdown

Output HP:

1/2

Output KW:

0.37

Output RPM:

1800

Frame NEMA:

S56C

Mount NEMA:

C-Face With Base

Input Voltage DC:

24

Full Load Amps:

20

Winding:

Permanent Magnet

Enclosure NEMA:

TENV

Product Information Packet
