1/4HP LEESON 60RPM 90VDC P1100 SERIES PARALLEL GEARMOTOR 108704
LEESON P1100 SERIES PARALLEL Totally enclosed, permanent magnet SCR rated DC gearmotor, performance matched for continuous duty service over a 60:1 speed range. All have constant torque throughout the range when powered by a full-wave unfiltered SCR-type adjustable speed control having a typical form factor of 1.3 to 1.4.
Gearbox has rugged aluminum die cast housing, for maximum gear and bearing support. Precision machined gearing, hardened for maximum load capability. All gearing designed and rated to AGMA Class 9 standards and to withstand momentary shock overload of 200%. Oversized output bearings for greater overhung load capacity and longer life. High-carbon alloy output shaft provides maximum strength and rigidity. All needle bearing journals are precision-ground after heat treating, to provide maximum finish and fit. Heavy-duty industrial oil seals help keep lubricant in and dirt out. Gears and bearings are splash lubricated with permanent, heavy-duty gear oil. Conduit box is included as standard.
These gearmotors are designed for mounting at any angle, but shaft up with motor below gearhead is not recommended. Overhung load capacities shown are at center of output shaft. P1100 DC gearmotors have the same mounting dimensions as Bison 483 gearmotors and many Dayton gearmotors.
The motor’s stall torque exceeds recommended full load torques. A current limiting device such as an SCR control should be used to prevent damage.
|HPKW||1/4||F.L. Amps||2.7||F.L. Amps|
|Frame||P1102-48||S. F Amps||S. F Amps|
|Model #||C4D17NZ21||Serv. Factor||1.0||PF|
|Eff 100%||Eff 75%||Enclosure||TENV|
|Series||Overhung Ld.||625||Shaft Type||PARALLEL|
