1HP LEESON 1800RPM 56C TEFC 12VDC MOTOR 108322.00

Catalog Number:  108322.00
Model Number:  C4D17FK28C
Description:  1HP,1800RPM,56C,TEFC,12VDC
Ship Weight:  37 lbs.
  • Battery Termal Connection Studs at 12:00.
  • 5/8 Keyed output shaft

Mechanical Features: Unique brush holder design provides easy access to brushes and integral, constant pressure brush/spring assembly for servicing. Larger over-sized brushes assure longer brush life. Heavy-duty, stamped steel, bolt-on base (removable). NEMA C face mounting flange at no additional cost. High strength rolled steel frame. Rugged die cast aluminum endshields with steel bearing inserts. Permanently lubricated sealed ball bearings. May be converted to NEMA 48 frame base dimensions or NEMA 42/48 frame C face dimensions using modification kit. See DC motor parts category for accessories.

Electrical Features: High starting torques for heavy load applications. Linear speed/torque characteristics over entire speed range. Capable of dynamic braking for faster stops. Reversible rotation and simple two-lead connection. Convenient wiring access.

RPM 1800 HP 1 Serv. Factor 1.0
KW   Form Factor 1.0 Amps 80
KW2   Form Factor 2   FLA2
Volts 12 Frame 56C
Max Amb 40 Duty CONT TYPE DF
Insul Class H Enclosure TEFC Bearing OPE 6203
Protection NOT Protector   Bearing PE 6203
EFF 77.9% Torque 35 LB-IN
UL Yes CSA Yes CE No
Motor Wt. 42 LB Nameplate 080209 Lubrication POLYREX EM
Carton Label Leeson Gen Purpose
Assembly   Mounting C-Face Rigid Rotation RECONN
1HP LEESON 1800RPM 56C TEFC 12VDC MOTOR 108322.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 108322.00
Stock # 108322
Price: $450.00
Compare At: $1,135.00
