1/2HP LEESON 3450RPM 56C DP 1PH MOTOR 103024.00

LEESON 103024.00 has been superseded by E103024.00

Catalog Number:  103024.00
Model Number:  C4C34DK10A
Description:  1/2HP,3450RPM,56C,DP,1PH,60HZ
Ship Weight:  20 lbs.

APPLICATIONS: For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.

FEATURES:

  • Durable rolled steel frame
  • 5/8" shaft output diameter
  • High-quality ball bearings
  • Capacitor Start
  • Easy-to-read nameplate
  • UL Recognized Component Listing and CSA approval
  • Non USA Manufactured, MX
  • 1 year warranty
Volts 115 Volts 208-230 Volts
F.L. Amps 6.8 F.L. Amps 3.3-3.4 F.L. Amps
S. F Amps 7.6 S. F Amps 3.9-3.8 S. F Amps
RPM 3600 Hertz 60
HP 1/2 Duty CONTINUOUS TYPE CD
KW .373 Model # C4C34DK10A
Frame S56C Serv. Factor 1.25 Phase 1
Max Amb 40 Design N Code L
Insul Class B Protection NOT Therm.Prot.
Eff 100% 66 Eff 75%   PF 71
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number EXEMPT CE No Bearing PE 6203
Load Type   Inverter Type NONE Speed Range NONE
Motor Wt. 20 LB Enclosure DP Lubrication STANDARD
Nameplate A-92005-12 Mounting RIGID Rotation SELECTIVE CCW
1/2HP LEESON 3450RPM 56C DP 1PH MOTOR 103024.00
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: 103024.00
Stock # 103024
Price: $160.00
Compare At: $384.00
