1/2HP LEESON 1725RPM 56C DP 3PH MOTOR 103022.00

LEESON 103022.00 has been superseded by E119353.00

Catalog Number:  103022.00
Model Number:  C4T17DK10A
Description:  1/2HP,1725RPM,56C,DP,3PH,60/50HZ
Ship Weight:  26 lbs.
Volts 208-230 Volts 460 Volts 190/380
F.L. Amps 1.8-1.8 F.L. Amps .9 F.L. Amps 2/1
S. F Amps 2-2 S. F Amps 1 S. F Amps
RPM 1800 Hertz 60/50
HP 1/2 Duty CONTINUOUS TYPE TD
KW 0.37 Model Number C4T17DK10A
Frame S56C Serv. Factor 1.25 Phase 3
Max Amb 40 Design NO DESIGN CODE Code M
Insul Class F Protection AUTOMATIC Therm.Prot. 7AM035A5
Eff 100% 77 Eff 75%   PF 69
UL Y-(LEESON UL REC) CSA Yes Bearing OPE 6203
CC Number EXEMPT CE Yes Bearing PE 6203
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 26 LB Enclosure DP Lubrication MULTEMP SRL
Nameplate A-92005-19 Mounting RIGID Rotation REV
1/2HP LEESON 1725RPM 56C DP 3PH MOTOR 103022.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 103022.00
Stock # 103022
