1/2HP LEESON 3450RPM 56J DP 3PH MOTOR 102199

Catalog Number:  102199.00 - FREE Ground Shipping in USA
Model Number:  C4T34DK8
Description:  1/2HP,3450RPM,56J,DP,3PH,60HZ
Ship Weight:  20 lbs.

Three Phase DP Jet Pump Motor for industrial or commercial service.

  • Made in the USA
  • Steel frame
  • NEMA 56 C face mounting flange, with base
  • Threaded shafts made of 303 grade stainless steel
  • CCW rotation facing lead end
  • Quiet flow-through ventilation system
  • Double sealed bearings on shaft end
  • Terminal board with quick connects
  • Locked shaft end bearings
  • UL recognized and CSA certified
Volts 208-230   Volts 460   Volts
FL Amps 1.6-1.8   FL Amps .9   FL Amps
SF Amps 1.8-2   SF Amps 1   SF Amps
RPM 3600   Hertz 60
HP 1/2   Duty CONTINUOUS   Type TD
KW .37   SF 1.25   Phase 3
Frame S56J   Design NO DESIGN CODE   KVA Code L
Ambient 40   Protection NOT   Therm.Prot.
Insulation Class B   Eff(75%)     PF 75
Eff(100%) 69   CSA Y   Bearing OPE 6203
UL Y   CE N   Bearing PE 6203
CC Number     Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 20 LB   Enclosure DP   Lubrication POLYREX EM
Nameplate 004002   Mounting RIGID   Rotation REV
Shaft Diam. 5/8 IN   Cust Part No.     Packaging B
      Winding T55221   Carton Label Leeson Pump
      Group 3   Iris
Paint BLUE - LEESON (ENAMEL)   Hazardous Location NONE   Test Card 02
1/2HP LEESON 3450RPM 56J DP 3PH MOTOR 102199
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 102199.00
Stock # 102199
Price: $199.00
Compare At: $495.00
