1/2HP LEESON 3450RPM 56J DP 3PH MOTOR 102198

Catalog Number:  102198.00 - FREE Ground Shipping in USA
Model Number: C4T34DC26
Description:  1/2HP,3450RPM,56J,DP,3PH,60HZ
Ship Weight:  20 lbs.

Three Phase DP Jet Pump Motor for industrial and commercial service.


  • Made in the USA
  • Steel frame
  • NEMA 56 C face mounting flange, no base
  • Threaded shafts made of 303 grade stainless steel
  • CCW rotation facing lead end
  • Quiet flow-through ventilation system
  • Double sealed bearings on shaft end
  • Terminal board with quick connects
  • Locked shaft end bearings
  • UL recognized and CSA certified
Volts 208-230   Volts 460   Volts
FL Amps 1.6-1.8   FL Amps .9   FL Amps
SF Amps 1.8-2   SF Amps 1   SF Amps
RPM 3600   Hertz 60
HP 1/2   Duty CONTINUOUS   Type TD
KW .37   SF 1.25   Phase 3
Frame S56J   Design NO DESIGN CODE   KVA Code L
Ambient 40   Protection NOT   Therm.Prot.
Insulation Class B   Eff(75%)     PF 75
Eff(100%) 69   CSA Y   Bearing OPE 6203
UL Y   CE N   Bearing PE 6203
CC Number EXEMPT   Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 20 LB   Enclosure DP   Lubrication POLYREX EM
Nameplate 004002   Mounting ROUND   Rotation REV
Shaft Diam. 5/8 IN   Cust Part No.     Packaging B
      Winding T55221   Carton Label Leeson Pump
      Group 3   Iris
Paint BLUE - LEESON (ENAMEL)   Hazardous Location NONE   Test Card 02
1/2HP LEESON 3450RPM 56J DP 3PH MOTOR 102198
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 102198.00
Stock # 102198
Price: $201.00
Compare At: $435.00

Product Reviews

Write a review now

Submitted by maninmotion on
Replaced old AO Smith motor with this Leeson pump motor and what a difference! Very Happy!
