1/3HP LEESON 3450RPM 56J DP 3PH MOTOR 102197

Catalog Number:  102197.00 - FREE Ground Shipping in USA
Model Number:  C4T34DC25
Description:  1/3HP,3450RPM,56J,DP,3PH,60HZ
Ship Weight:  16 lbs.

This Leeson motor is a Build To Order product and factory lead times are approximately 3-8 weeks after receipt of order. For exact lead times or other interchangeable products please contact our sales team for particulars.

DP Three Phase Jet Pump Motor for industrial and commercial service.

FEATURES:

  • Made in the USA
  • Steel frame
  • NEMA 56 C-face mounting flange, no base
  • Threaded shaft made of 303 grade stainless steel
  • CCW rotation facing lead end
  • Quiet flow-through ventilation system
  • Double sealed bearings on shaft end
  • Terminal board with quick connects
  • Locked shaft end bearings
  • UL recognized and CSA certified
Volts 230   Volts 460   Volts
FL Amps 1.4   FL Amps .7   FL Amps
SF Amps 1.6   SF Amps .8   SF Amps
RPM 3600   Hertz 60
HP 1/3   Duty CONTINUOUS   Type TD
KW .246   SF 1.35   Phase 3
Frame S56J   Design NO DESIGN CODE   KVA Code L
Ambient 40   Protection NOT   Therm.Prot.
Insulation Class B   Eff(75%)     PF 74
Eff(100%) 68   CSA Y   Bearing OPE 6203
UL Y   CE N   Bearing PE 6203
CC Number     Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 16 LB   Enclosure DP   Lubrication POLYREX EM
Nameplate 004002   Mounting ROUND   Rotation REV
Shaft Diam. 5/8 IN   Cust Part No.     Packaging B
      Winding T5526   Carton Label Leeson Pump
      Group 3   Iris
Paint BLUE - LEESON (ENAMEL)   Hazardous Location NONE   Test Card 02
1/3HP LEESON 3450RPM 56J DP 3PH MOTOR 102197
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 102197.00
Stock # 102197
Price: $166.00
Compare At: $413.00
