3/4HP LEESON 3450RPM 56J DP 3PH MOTOR 101637

Catalog Number:  101637.00 - FREE Ground Shipping in USA
Model Number:  C4T34DC20
Description:  3/4HP,3450RPM,56J,DP,3PH,60HZ
Ship Weight:  21 lbs.

Three Phase DP Jet Pump Motor for industrial and commercial service.

FEATURES:

  • Made in the USA
  • Steel frame
  • NEMA 56 C face mounting flange, no base
  • Threaded shafts made of 303 grade stainless steel
  • CCW rotation facing lead end
  • Quiet flow-through ventilation system
  • Double sealed bearings on shaft end
  • Terminal board with quick connects
  • Locked shaft end bearings
  • UL recognized and CSA certified
Volts 230   Volts 460   Volts 190/380
FL Amps 2.4   FL Amps 1.2   FL Amps 2/1
SF Amps 2.8   SF Amps 1.4   SF Amps 2.1/1.1
RPM 3600   Hertz 60/50
HP 3/4   Duty CONTINUOUS   Type TD
KW .56   SF 1.15   Phase 3
Frame S56J   Design NO DESIGN CODE   KVA Code K
Ambient 40   Protection NOT   Therm.Prot.
Insulation Class B   Eff(75%)     PF 74
Eff(100%) 79   CSA Y   Bearing OPE 6203
UL Y-(LEESON UL REC)   CE N   Bearing PE 6203
CC Number EXEMPT   Inverter Type     Speed Range NONE
LOad Type
Motor Wt. 21 LB   Enclosure DP   Lubrication POLYREX EM
Nameplate 004002   Mounting ROUND   Rotation REV
Shaft Diam. 5/8 IN   Cust Part No.     Packaging B
      Winding T5527   Carton Label Leeson Pump
      Group 3   Iris
Paint BLUE - LEESON (ENAMEL)   Hazardous Location NONE   Test Card 02
3/4HP LEESON 3450RPM 56J DP 3PH MOTOR 101637
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 101637.00
Stock # 101637
Price: $197.00
Compare At: $524.00
