1/3HP LEESON 3450RPM 48 DP 3PH MOTOR 101447.00

LEESON 101447.00 has been superseded by E101447.00

Catalog Number:  101447.00 Made in USA
Model Number:  C4T34DB3D
Description:  1/3HP,3450RPM,48,DP,3PH,60HZ
Ship Weight:  15 lbs.

DP Models: For use where water and dust exposure is moderate. Ideally suited for use on pumps, compressors, blowers, fans, and other direct or belt-driven applications.


  • Made in USA
  • 1/2" shaft output diameter
  • Durable rolled steel frame
  • High-quality ball bearings
  • Easy-to-read nameplate
  • UL Recognized Component Listing and CSA approval.
  • Warranty – 12 months from date of first use or 18 months from date of manufacture, whichever comes first.
Volts 208-230 Volts 460 Volts 208-230/460
F.L. Amps 1.4-1.4 F.L. Amps .7 F.L. Amps 1.7/.85
S. F Amps 1.5-1.6 S. F Amps .8 S. F Amps 1.8/.9
RPM 3600 Hertz 60/50
KW 0.25 Model Number C4T34DB3D
Frame 48 Serv. Factor 1.35 Phase 3
Max Amb 40 Design NO DESIGN CODE Code L
Insul Class B Protection NOT Therm.Prot.
Eff 100% 68 Eff 75%   PF 74
UL Yes CSA Yes Bearing OPE 6203
CC Number EXEMPT CE No Bearing PE 6203
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 15 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004002 Mounting RIGID Rotation REV
1/3HP LEESON 3450RPM 48 DP 3PH MOTOR 101447.00
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 101447.00
Stock # 101447
