1/3HP LEESON 3450RPM 56C DP 3PH MOTOR 100375

LEESON 100375.00 has been superseded by E100375.00

Catalog Number:  100375.00
Description:  1/3HP,3450RPM,56C,DP,3PH,60HZ
Ship Weight:  16 lbs.
Volts 208-230 Volts 460 Volts 208-230/460
F.L. Amps 1.4-1.4 F.L. Amps .7 F.L. Amps 1.7/.85
S. F Amps 1.5-1.6 S. F Amps .8 S. F Amps 1.8/.9
RPM 3600 Hertz 60/50
KW 0.25 Model Number C4T34DC2 E
Frame 48C Serv. Factor 1.35 Phase 3
Max Amb 40 Design NO DESIGN CODE Code L
Insul Class B Protection NOT Therm.Prot.
Eff 100% 68 Eff 75%   PF 74
UL Yes CSA Yes Bearing OPE 6203
CC Number EXEMPT CE No Bearing PE 6203
Load Type   Inverter Type   Speed Range NONE
Motor Wt. 16 LB Enclosure DP Lubrication POLYREX EM
Nameplate 004002 Mounting C FACE Rotation REV
1/3HP LEESON 3450RPM 56C DP 3PH MOTOR 100375
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: 100375.00
Stock # 100375
