002789.01 LEESON IR SERIES 115VAC 25A SOLID STATE SINPAC REVERSING SWITCH

002789.01 LEESON IR SERIES 115VAC 25A SOLID STATE SINPAC REVERSING SWITCH

Picture is for reference only.

Part Number:

002789.01

Model/Spec Number:

IR-25-165

Manufacturer:

Stearns Obsolete

Manufacturer Part Number:

4-7-51025-15-U03
002789.01 LEESON IR SERIES 115VAC 25A SOLID STATE SINPAC REVERSING SWITCH

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Weight:

2 lbs

Dimensions:

5 x 5 x 3 inches

HS Code:

8536507000

Technical Details

Cut Out Voltage:

165 VCO

Max Amperage Rating:

25 Amps

Package Style:

Cap Case 1.822 dia. x 3.372 long

Series:

Capacitor Start Instant Reverse

Start Winding Voltage:

115VAC

IR IRV Series

Sinpac Installation Instructions

  • IR Series
  • Instant Reversing for Capacitor Start Motors Only
  • 115V 50/60Hz Start Circuit Voltage
  • Standard 25 Amps
  • Capacitor Case 1.822 dia. x 3.372 long
  • UL Recognized
  • 165 VCO
