VM7002A BALDOR 1/2HP EXPLOSION PROOF MOTOR 34-5336-5723

Electric Motors

Discontinued Electric Motors

Baldor Discontinued Motors

1/3HP BALDOR 1725RPM 56C XPFC 3PH EXPLOSION PROOF MOTOR VM7002A

Picture is for reference only.

Part Number:

VM7002A

Model/Spec Number:

34-5336-5723

Manufacturer:

Baldor Obsolete Motors

VM7002A BALDOR 1/3HP Explosion Proof Motor is ideal for hazardous location applications driving pumps, compressors, blowers, fans, and many other loads that require hazardous location protection.

Item Discontinued

Click below to view suggested functional replacement.

See Replacement Item

Shipping Details

Weight:

27 lbs

Dimensions:

16 x 20 x 16 inches

HS Code:

8501.51.4000

UPC:

781568111871

Technical Details

Specifications

Brand:	Baldor
Application:	Explosion Proof
Output HP:	1/3
Output KW:	0.25
Output RPM:	1725
Frame Size NEMA:	56C
Mount NEMA:	C Face No Base
Enclosure NEMA:	XPFC
Enclosure IEC:	IP54
Voltage:	208-230/460

Documentation

VM7002A-InfoPacket

Explosion-Proof-Definitions

Additional Information

Division 1 Explosion Proof motors are designed and built to contain an explosion inside and not propagate it into the surrounding atmosphere.

APPLICATIONS: Pumps, fans and conveyors with fixed speed operation

FEATURES:

Threaded lead inlet
UL Certification markings
Robust Steel frame designs

CAUTION: Explosion-proof motors have a tight fit between mating parts to ensure the integrity of the explosion-proof enclosure. This can lead to an accumulation of moisture inside the motors due to condensation. If internal condensation buildup is a concern for your XP motor application, select a motor that includes UL listed breather drain. Care should be used when selecting an explosion-proof motor, especially when installed outdoors and on intermittent duty. Consider Drill Rig Duty Explosion-proof motors for outdoor applications. This explosion-proof motors is not suitable for use with adjustable speed drives "VFD".
