5HP BALDOR 1750RPM 184HP ODP 3PH SUPER-E PUMP MOTOR VHEM3218T

5HP BALDOR 1750RPM 184HP ODP 3PH SUPER-E PUMP MOTOR VHEM3218T

Picture is for reference only.

Part Number:

VHEM3218T

Model/Spec Number:

06F867X182G1

Manufacturer:

Baldor Obsolete Motors
VHEM3218T BALDOR 5HP P-Base Vertical Solid Shaft Pump Motors are designed for normal thrust applications. Waste water treatment plants, petro-chemical, pulp and plants and agricultural irrigation application.

Item Discontinued

Click below to request an agent review potential options.

Weight:

123 lbs

Dimensions:

13 x 26 x 13 inches

HS Code:

8501.52.4000

UPC:

781568827123

Technical Details

Brand:

Baldor

Application:

Severe Duty

Output HP:

5

Output KW:

3.7

Output RPM:

1750

Frame Size NEMA:

184HP

Mount NEMA:

P Base Normal

Enclosure NEMA:

ODP

Voltage:

230/460

Frequency (Hz):

60

VHEM3218T-InfoPacket.pdf
