25HP BALDOR 3520RPM 256HP OPEN 3PH SUPER-E PUMP MOTOR VHEM2516T

25HP BALDOR 3520RPM 256HP OPEN 3PH SUPER-E PUMP MOTOR VHEM2516T

Picture is for reference only.

Part Number:

VHEM2516T

Model/Spec Number:

09G625T577G1

Manufacturer:

Baldor Obsolete Motors
VHEM2516T BALDOR 25HP P-Base Vertical Solid Shaft Pump Motors are designed for normal thrust applications. Waste water treatment plants, petro-chemical, pulp and plants and agricultural irrigation application.

Item Discontinued

Click below to request an agent review potential options.

Weight:

287 lbs

Dimensions:

24 x 32 x 24 inches

HS Code:

8501.52.8040

UPC:

781568827079

Technical Details

Brand:

Baldor

Application:

Severe Duty

Output HP:

25

Output KW:

18.5

Output RPM:

3520

Frame Size NEMA:

256HP

Mount NEMA:

P Base Normal

Enclosure NEMA:

OPEN

Voltage:

230/460

Frequency (Hz):

60

VHEM2516T-InfoPacket.pdf
