5HP BALDOR 1750RPM 184TC TEFC 3PH MOTOR VEM3615T

Catalog Number: VEM3615T
Spec Number: 36A003S268G2
Description: 5HP,1750RPM,184TC,TEFC,3PH,60HZ,SUPER-E
Ship Weight: 88 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS: Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Ball Bearings
  • 1 1/8" keyed output shaft
  • Suitable for mounting any position
  • Heavy gauge steel frames
  • ISR® (Inverter Spike Resistant®) copper windings
  • Low-loss electrical grade lamination steel
  • 3 year warranty
SPEC. NUMBER: 36A003S268G2
CATALOG NUMBER: VEM3615T
FL AMPS: 13.9-13.4/6.7
208V AMPS: 13.9
BEARING-DRIVE-END: 6206
BEARING-OPP-DRIVE-END: 6205
DESIGN CODE: B
DOE-CODE: 010A
FL EFFICIENCY: 89.5
ENCLOSURE: TEFC
FRAME: 184TC
HERTZ: 60
INSULATION-CLASS: F
KVA-CODE: J
SPEED [rpm]: 1750
OUTPUT [hp]: 5
PHASE: 3
POWER-FACTOR: 78
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
VOLTAGE: 208-230/460
5HP BALDOR 1750RPM 184TC TEFC 3PH MOTOR VEM3615T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: VEM3615T
Stock # VEM3615T
Price: $467.00
Compare At: $991.00
