30HP BALDOR 1765RPM 326U TEFC 3PH MOTOR M4104

Catalog Number:  M4104
Description:  30HP,1765RPM,326U,TEFC,3PH,60HZ
Ship Weight:  423 lbs.

APPLICATIONS: Pumps, Air compressors, fans, conveyors, machine tools and other applications where three phase power is available.

FEATURES:

  • Ball bearings
  • Suitable for mounting any position
  • Heavy gauge steel and cast iron frames
SPEC. NUMBER: 10F644X259H2
CATALOG NUMBER: M4104
FL AMPS: 74/37
208V AMPS: 79
BEARING-DRIVE-END: 6312
BEARING-OPP-DRIVE-END: 6309
DESIGN CODE: B
DOE-CODE: 010A
FL EFFICIENCY: 92.4
ENCLOSURE: TEFC
FRAME: 326U
HERTZ: 60
INSULATION-CLASS: F
KVA-CODE: G
SPEED [rpm]: 1765
OUTPUT [hp]: 30
PHASE: 3
POWER-FACTOR: 82
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
VOLTAGE: 230/460
30HP BALDOR 1765RPM 326U TEFC 3PH MOTOR M4104
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: M4104
Stock # M4104
Price: $3,905.00
Compare At: $6,806.00
Quantity:
