5/2.5HP BALDOR 1725/850RPM 215T TEFC 230V 3PH MOTOR M1508T
| Catalog Number: | M1508T |
| Spec Number: | 37A001S145 |
| Description: | 5/2.5HP,1725/850RPM,215T,TEFC,208-230V,3PH,60HZ,TWO SPEED |
| Ship Weight: | 134 lbs. |
This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.
APPLICATIONS: Designed for use in applications in which multiple speeds are required. Ideal with fans, blowers, machine tools, hoists, conveyors, pumps, where three phase power is available.
FEATURES:
- Heavy duty steel frame
- Lifting eye bold mounted at top center 215T frame and larger for easy handling
- Copper windings
- 1 3/8" Keyed output shaft
- Dynamically balanced rotor
| SPEC. NUMBER: | 37A001S145 |
| CATALOG NUMBER: | M1508T |
| FL AMPS: | 13/10.4 |
| 208V AMPS: | -- |
| BEARING-DRIVE-END: | 6307 |
| BEARING-OPP-DRIVE-END: | 6206 |
| DESIGN CODE: | B |
| DOE-CODE: | -- |
| FL EFFICIENCY: | -- |
| ENCLOSURE: | TEFC |
| FRAME: | 215T |
| HERTZ: | 60 |
| INSULATION-CLASS: | B |
| KVA-CODE: | K |
| SPEED [rpm]: | 1725/850 |
| OUTPUT [hp]: | 5/2.5 |
| PHASE: | 3 |
| POWER-FACTOR: | -- |
| RATING: | 40C AMB-CONT |
| SERIAL-NUMBER: | -- |
| SERVICE FACTOR: | 1.15 |
| VOLTAGE: | 208-230 |
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: M1508T
Stock # M1508T
