7.5/1.9HP BALDOR 1725/850RPM 215T ODP 230V 3PH MOTOR M1009T

Catalog Number:  M1009T
Spec Number:  37B01W616
Description:  7.5/1.9HP,1725/850RPM,215T,ODP,230V,3PH,60HZ,TWO SPEED
Ship Weight:  113 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS: Designed for use with fans, blowers, pumps, and where three phase power is available.

FEATURES:

  • Cast Iron frame
  • Lifting eye bolt mounted at top center 215T frame and larger for easy handling
  • Copper windings
  • 1 3/8" Keyed output shaft
  • Dynamically balanced rotor
CATALOG NUMBER: M1009T
FL AMPS: 20/7.5
208V AMPS: --
BEARING-DRIVE-END: 6307
BEARING-OPP-DRIVE-END: 6206
DESIGN CODE: B
DOE-CODE: --
FL EFFICIENCY: --
ENCLOSURE: OPEN
FRAME: 215T
HERTZ: 60
INSULATION-CLASS: B
KVA-CODE: J
SPEED [rpm]: 1725/850
OUTPUT [hp]: 7.5/1.9
PHASE: 3
POWER-FACTOR: --
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
SPEC. NUMBER: 37B01W616
VOLTAGE: 230
7.5/1.9HP BALDOR 1725/850RPM 215T ODP 230V 3PH MOTOR M1009T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: M1009T
Stock # M1009T
Price: $1,131.00
Compare At: $1,947.00
Quantity:
