1HP BALDOR 1800RPM 56J OPEN 208-230/460V 3PH MOTOR JM3116

Catalog Number:  JM3116
Specification Number:  34F038W990G1
Description:  1HP,1725RPM,56J,OPEN,208-230/460V,3PH,60HZ,JET PUMP
Ship Weight:  30 lbs.

APPLICATIONS: Residential and industrial pumps, swimming pool pumps, etc where three phase power is available.

FEATURES:

  • Corrosion resistant stainless steel shaft extension
  • Slotted opposite DE shaft for easy installation
  • Dynamically balanced rotor to reduce noise and increase bearing life
  • Optimized airflow design providing higher horsepower in a smaller package
  • Copper windings
SPEC. NUMBER: 34F038W990G1
CATALOG NUMBER: JM3116
FL AMPS: 3.7-3.4/1.7
208V AMPS: 3.7
BEARING-DRIVE-END: 6203
BEARING-OPP-DRIVE-END: 6203
DESIGN CODE: B
DOE-CODE: --
FL EFFICIENCY: 78.5
ENCLOSURE: OPEN
FRAME: 56J
HERTZ: 60
INSULATION-CLASS: F
KVA-CODE: K
SPEED [rpm]: 1725
OUTPUT [hp]: 1
PHASE: 3
POWER-FACTOR: 70
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
VOLTAGE: 208-230/460
1HP BALDOR 1800RPM 56J OPEN 208-230/460V 3PH MOTOR JM3116
Click Image to Enlarge
Manufacturer Part Number: JM3116
Stock # JM3116
Price: $344.26
Compare At: $489.00
