1/5HP BALDOR 50RPM TENV 90VDC RIGHT ANGLE GEARMOTOR GP7408
1/5HP BALDOR 50RPM TENV 90VDC RIGHT ANGLE GEARMOTOR GP7408
Picture is for reference only.
Part Number:
GP7408Model/Spec Number:
24A011Z054G1Manufacturer:
Baldor Obsolete MotorsClick below to request an agent review potential options.
Shipping Details
Weight:
14 lbsDimensions:
8 x 16 x 8 inchesHS Code:
8501.31.4000UPC:
781568124215Technical Details
Specifications
Design: | Right Angle Shaft |
Input HP: | 1/5 |
Output KW: | 0.149 |
Output RPM: | 50 |
Gear Ratio: | 45:1 |
Torque Lb-in.: | 120 |
Overhung Load (lb.): | 125 |
Voltage: | 90 |
Full Load Amperage: | 1.9 |
Application: | General Purpose |
Documentation
Additional Information
APPLICATIONS: Conveyors, medical and laboratory equipment, printing presses, machine tools and other applications requiring adjustable speed.
FEATURES:
- DCPM motor provides exceptional starting torque, adjustable speed and predictable performance
- Dual 3/4" (.750") Keyed output shafts
- Ball bearing on output for smooth torque transmission
- High strength bronze gearing
- Hardened and ground worm
- Permanently lubricated with synthetic Mobil SHC634 oil
- Internal oil expansion bladder allows for all position mounting without relocating a breather vent*
- Reversible
- Powder-coated enamel finish
- 3 ft. SJTO cord
