1/8HP BALDOR 6RPM TENV 90VDC RIGHT ANGLE GEARMOTOR GP7304
1/8HP BALDOR 6RPM TENV 90VDC RIGHT ANGLE GEARMOTOR GP7304
Picture is for reference only.
Part Number:
GP7304Model/Spec Number:
24A403Z071G1Manufacturer:
Baldor Obsolete MotorsClick below to request an agent review potential options.
Shipping Details
Weight:
13 lbsDimensions:
8 x 16 x 8 inchesHS Code:
8501312000UPC:
781568124208Technical Details
Specifications
Design: | Right Angle Shaft |
Input HP: | 1/8 |
Output KW: | 0.093 |
Output RPM: | 6 |
Gear Ratio: | 600:1 |
Torque Lb-in.: | 150 |
Overhung Load (lb.): | 95 |
Voltage: | 90 |
Full Load Amperage: | 0.82 |
Application: | General Purpose |
Documentation
Additional Information
APPLICATIONS: Conveyors, medical and laboratory equipment, printing presses, machine tools and other applications requiring adjustable speed.
FEATURES:
- DCPM motor provides exceptional starting torque, adjustable speed and predictable performance
- Dual 5/8" Keyed output shaft
- Ball bearing on output for smooth torque transmission
- High strength bronze gearing
- Hardened and ground worm
- Permanently lubricated with synthetic Mobil SHC634 oil
- Internal oil expansion bladder allows for all position mounting without relocating a breather vent*
- Reversible
- Powder-coated enamel finish
- 3 ft. SJTO cord
