1/2HP BALDOR 125RPM TENV 90VDC RIGHT ANGLE GEARMOTOR GP3303
1/2HP BALDOR 125RPM TENV 90VDC RIGHT ANGLE GEARMOTOR GP3303
Picture is for reference only.
Part Number:
GP3303Model/Spec Number:
33-2408Z148G1K3Manufacturer:
Baldor Obsolete MotorsClick below to request an agent review potential options.
Shipping Details
Weight:
30 lbsDimensions:
12 x 18 x 12 inchesHS Code:
8501.31.4000UPC:
781568757468Technical Details
Specifications
Design: | Right Angle Shaft |
Input HP: | 1/2 |
Output KW: | 0.373 |
Output RPM: | 125 |
Gear Ratio: | 20:1 |
Torque Lb-in.: | 145 |
Overhung Load (lb.): | 125 |
Voltage: | 90 |
Application: | General Purpose |
Frame Series: | JH |
Documentation
Additional Information
APPLICATIONS: Conveyors, medical and laboratory equipment, printing presses, machine tools and other applications requiring adjustable speed.
FEATURES:
- DCPM motor provides exceptional starting torque, adjustable speed and predictable performance
- Single 3/4" Keyed output shaft
- Ball bearing on output for smooth torque transmission
- High strength bronze gearing
- Hardened and ground worm
- Permanently lubricated with synthetic Mobil SHC634 oil
- Internal oil expansion bladder allows for all position mounting without relocating a breather vent*
- Reversible
- Powder-coated enamel finish
- 3 ft. SJTO cord
