BALDOR FX2-03-B7-140TC RATIO MULTIPLIER SPEED REDUCER GCF3X02BB

5 IN STOCK
Catalog Number:  GCF3X02BB
Description:  FX2-03-B7-140TC/RATIO MULTIPLIER
Output Shaft CONFIG:  INLINE
Ship Weight:  28 lbs.



APPLICATIONS: Can reduce or increase input speed when combined with right angle units for high ratios. 4 ratios available. Interchangeable with Grove TX/TXQ series. Custom style "SX" can be back driven in increase motor speed. Max output speed, 4500 RPMS.

FEATURES:

  • High efficiency
  • Cast iron construction
  • Universal mounting positions
  • Optional base mounting
  • Internal compression chamber eliminates breather vent
  • Shipped with synthetic oil
  • Lubricated for life with Klubersynth GH6-150
Catalog Number: GCF3X02BB
Specification Number: GR0236A015
Style Number: FX2-03-B7-140TC
Ratio: 3
Max. Input HP: 8.69
Max. Torque rating(in-lbs.): 911
Output RPM @ 1750: 583
C-Face Motor NEMA Frame Size: 140TC
BALDOR FX2-03-B7-140TC RATIO MULTIPLIER SPEED REDUCER GCF3X02BB
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: FX2-03-B7-140TC
Stock # GCF3X02BB
Price: $340.00
Compare At: $553.00
Quantity:
