5HP BALDOR 1160RPM 215T XPFC 3PH MOTOR EM7040T

BALDOR Catalog Number:  EM7040T
Description:  5HP,1160RPM,215T,XPFC,3PH,60//50HZ,SUPER-E
Ship Weight:  170 lbs.

APPLICATIONS: Ideal for wide variety of applications where hazardous fumes or dust may be present.

FEATURES:

  • U.L. and CSA approved for Class I, Group D, Class II, Group F & G, T3C
  • Available in 182T through 449T frames (-c models)
  • Corrosion resistant epoxy finish
  • U.L. approved cast conduit box standard
  • 1.00 Service Factor
  • EM Super-E® explosion proof motors have NEMA premium efficiency and 3 year warranty.

CAUTION: Explosion-proof motors have a tight fit between mating parts to ensure the integrity of the explosion-proof enclosure. This can lead to an accumulation of moisture inside the motors due to condensation. Care should be used when selecting an explosion-proof motor, especially when installed outdoors and on intermittent duty. Consider Drill Rig Duty Explosion-proof motors for outdoor applications. These explosion-proof motors are not suitable for use with adjustable speed drives "VFD", inverter duty explosion-proof motors must be used.

SPEC. NUMBER: 37H239S838G1
CATALOG NUMBER: EM7040T
FL AMPS: 14.6/7.3//11.6/5.8
208V AMPS: 15.3
DESIGN CODE: A
DOE-CODE: 010A
FL EFFICIENCY: 89.5
FRAME: 215T
HERTZ: 60//50
INSULATION-CLASS: B
KVA-CODE: K
SPEED [rpm]: 1160//960
NAMEPLATE-SERIAL-NUMBER: --
OUTPUT [hp]: 5//3
PHASE: 3
POWER-FACTOR: 72
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.00
TEMP. CODE: T3C
VOLTAGE: 230/460//190/380
5HP BALDOR 1160RPM 215T XPFC 3PH MOTOR EM7040T
Click Image to Enlarge
Manufacturer Part Number: EM7040T
Stock # EM7040T
Price: $1,666.00
Compare At: $2,868.00
