25HP BALDOR 1770RPM 284T TEFC 3PH MOTOR EM4103T

Catalog Number: EM4103T
Spec Number: 10C151X209G1
Description: 25HP,1770RPM,284T,TEFC,3PH,60HZ,SUPER-E
Ship Weight: 388 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

BALDOR Super-E Motors are designed to conserve energy over extended time periods. These premium efficiency designs are available in both Totally Enclosed Fan Cooled and Open Drip Proof construction. All three phase motors are Inverter Ready per NEMA Standard MG1, Part 31.4.4.2. This means the motors in 230 and 460 volts meet NEMA's corona inception voltage requirements, under this Standard, and can withstand peak voltages of up to 1600 volts.

APPLICATIONS: Pumps, compressors, fans, conveyors, machine tools and other applications where three phase power is available.

FEATURES:

  • Ball bearings
  • Suitable for mounting any position
  • Heavy gauge steel and cast iron frames
208V AMPS: 63.3
BEARING-DRIVE-END: 6311
BEARING-OPP-DRIVE-END: 6309
CUSTOMER-PART-NUMBER: --
DESIGN CODE: B
DOE-CODE: 010A
FL EFFICIENCY: 93.6
ENCLOSURE: TEFC
FRAME: 284T
GREASE: POLYREX EM
HERTZ: 60
CATALOG NUMBER: EM4103T
SPEC. NUMBER: 10C151X209G1
INSULATION-CLASS: F
KVA-CODE: G
MAX. SPACE HEATER TEMP.: --
SPEED [rpm]: 1770
OUTPUT [hp]: 25
PHASE: 3
POWER-FACTOR: 84
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
SPACE-HEATER-AMPS: --
SPACE-HEATER-VOLTS: --
VOLTAGE: 230/460
FL AMPS: 60/30
25HP BALDOR 1770RPM 284T TEFC 3PH MOTOR EM4103T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: EM4103T
Stock # EM4103T
Price: $1,855.00
Compare At: $3,657.00
