150HP BALDOR 1190RPM 445T OPEN 3PH MOTOR EM2560T-4

Catalog Number:  EM2560T-4
Description: 150HP,1190RPM,445T,OPEN,3PH,SUPER-E
Ship Weight:  1572 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS:

Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Heavy duty frames
  • Ball bearings
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Low-loss electrical lamination grade steel
  • Three year warranty.
FL AMPS: 175
BRG-DE-AFBMA: 90BC03J30X
BRG-ODE-AFBMA: 90BC03J30X
DESIGN CODE: B
DUTY: CONT
FL EFFICIENCY: 95.4
EFFICIENCY-2: 95.0
EFFICIENCY-3: --
ENCLOSURE: PROT
FRAME: 445T
HERTZ: 60
INSULATION CLASS: F
CATALOG NUMBER: EM2560T-4
SPEC. NUMBER: P44G1780
AMBIENT-TEMPERATURE: 40
MAX. KVAR: 35.0
SPEED [rpm]: 1185
MOTOR-WEIGHT: --
NP-FREE-TEXT-01: --
NP-FREE-TEXT-02: --
NP-FREE-TEXT-03: --
OUTPUT [hp]: 150
PHASE: 3
POWER-FACTOR: 84
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
TYPE: P
VOLTAGE: 460
KVA-CODE: G
150HP BALDOR 1190RPM 445T OPEN 3PH MOTOR EM2560T-4
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: EM2560T-4
Stock # EM2560T-4
Price: $8,557.00
Compare At: $15,963.00
