150HP BALDOR 1780RPM 444T OPEN 3PH MOTOR EM2558T-4

Catalog Number:  EM2558T-4
Description: 150HP,1780RPM,444T,OPEN,3PH,SUPER-E
Ship Weight:  1528 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS:

Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Heavy duty frames
  • Ball bearings
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Low-loss electrical lamination grade steel
  • Three year warranty.
208V AMPS: --
BEARING-DRIVE-END: 6312
BEARING-OPP-DRIVE-END: 6312
CUSTOMER-PART-NUMBER: --
DESIGN CODE: A
DOE-CODE: 010A
FL EFFICIENCY: 95.8
ENCLOSURE: OPSB
FRAME: 405TS
GREASE: POLYREX EM
CATALOG NUMBER: EM2556T-4
SPEC. NUMBER: 44E194W220
FL AMPS: 164
INSULATION-CLASS: F
KVA-CODE: H
SPEED [rpm]: 3560
OUTPUT [hp]: 150
PHASE: 3
POWER-FACTOR: 89
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
SPACE-HEATER-AMPS: --
SPACE-HEATER-VOLTS: --
VOLTAGE: 460
HERTZ: 60
150HP BALDOR 1780RPM 444T OPEN 3PH MOTOR EM2558T-4
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: EM2558T-4
Stock # EM2558T-4
Price: $6,544.00
Compare At: $12,208.00
