60HP BALDOR 1185RPM 404T OPEN 3PH MOTOR EM2548T-4CI

Catalog Number:  EM2548T-4CI
Description: 60HP,1185RPM,404T,OPEN,3PH,SUPER-E
Ship Weight:  1009 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS:

Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Heavy duty frames
  • Ball bearings
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Low-loss electrical lamination grade steel
  • Three year warranty.
AG-BLANK-LINE-1B: --
AG-BLANK-LINE-2A: --
AG-BLANK-LINE-2B: --
AMBIENT-TEMPERATURE: 40
FL AMPS: 70.4
BRG-DE-AFBMA: 80BC03J30X
BRG-ODE-AFBMA: 80BC03J30X
DESIGN CODE: B
DUTY: CONT
FL EFFICIENCY: 95
ENCLOSURE: DP
CATALOG NUMBER: EM2548T-4CI
SPEC. NUMBER: P40G4411
FRAME: 404T
HERTZ: 60
INSULATION CLASS: F
KVA-CODE: G
SPEED [rpm]: 1185
MOTOR-WEIGHT: --
OUTPUT [hp]: 60
PHASE: 3
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
TYPE: P
VOLTAGE: 460
AG-BLANK-LINE-1A: --
60HP BALDOR 1185RPM 404T OPEN 3PH MOTOR EM2548T-4CI
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: EM2548T-4CI
Stock # EM2548T-4CI
Price: $5,536.00
Compare At: $10,242.00
