60HP BALDOR 1780RPM 364T OPSB 3PH MOTOR EM2547T-CI

Catalog Number:  EM2547T-CI
Description: 60HP,1780RPM,364T,OPSB,3PH,SUPER-E
Ship Weight:  704 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS:

Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Heavy duty frames
  • Ball bearings
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Low-loss electrical lamination grade steel
  • Three year warranty.
AG-BLANK-LINE-2A: --
AG-BLANK-LINE-3A: --
AMBIENT-TEMPERATURE: 40
FL AMPS: 139/69.5
BRG-DE-AFBMA: 65BC03J30X
BRG-ODE-AFBMA: 65BC03J30X
DESIGN CODE: B
DUTY: CONT
FL EFFICIENCY: 95
EFFICIENCY-2: 94.5
EFFICIENCY-3: --
ENCLOSURE: DP
CATALOG NUMBER: EM2547T-CI
SPEC. NUMBER: P36G51
AG-BLANK-LINE-1A: --
HERTZ: 60
INSULATION CLASS: F
KVA-CODE: G
MAX. KVAR: 12.5
SPEED [rpm]: 1780
MOTOR-WEIGHT: --
OUTPUT [hp]: 60
PHASE: 3
POWER-FACTOR: 85.5
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
TYPE: P
VOLTAGE: 230/460
FRAME: 364T
60HP BALDOR 1780RPM 364T OPSB 3PH MOTOR EM2547T-CI
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: EM2547T-CI
Stock # EM2547T-CI
Price: $3,696.00
Compare At: $6,838.00
