40HP BALDOR 3540RPM 286TS OPSB 200V 3PH MOTOR EM2538T-8

Catalog Number:  EM2538T-8
Description: 40HP,3540RPM,286TS,OPSB,200V,3PH,SUPER-E
Ship Weight:  362 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS: Typical applications include Pumps, fans, compressors, blowers, machine tools, conveyors and many other applications requiring 200 volt power. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Heavy duty frames
  • 200 VAC
  • Ball bearings
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Low-loss electrical lamination grade steel
  • Three year warranty.
SPEC. NUMBER: 40G051X239
CATALOG NUMBER: EM2538T-8
FL AMPS: 105
208V AMPS: --
BEARING-DRIVE-END: 6311
BEARING-OPP-DRIVE-END: 6309
CUSTOMER-PART-NUMBER: --
DESIGN CODE: B
DOE-CODE: 010A
FL EFFICIENCY: 92.4
ENCLOSURE: OPSB
FRAME: 286TS
GREASE: POLYREX EM
HERTZ: 60
INSULATION-CLASS: F
KVA-CODE: G
MAX. SPACE HEATER TEMP.: --
SPEED [rpm]: 3530
OUTPUT [hp]: 40
PHASE: 3
POWER-FACTOR: 89
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
SPACE-HEATER-AMPS: --
SPACE-HEATER-VOLTS: --
VOLTAGE: 200
40HP BALDOR 3540RPM 286TS OPSB 200V 3PH MOTOR EM2538T-8
Click Image to Enlarge
Manufacturer Part Number: EM2538T-8
Stock # EM2538T-8
Price: $2,370.00
Compare At: $4,385.00
