30HP BALDOR 1770RPM 286T OPSB 200V 3PH MOTOR EM2535T-8

Catalog Number:  EM2535T-8
Description: 30HP,1770RPM,286T,OPSB,200V,3PH,SUPER-E
Ship Weight:  278 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS: Typical applications include Pumps, fans, compressors, blowers, machine tools, conveyors and many other applications requiring 200 volt power. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Heavy duty frames
  • 200 VAC
  • Ball bearings
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Low-loss electrical lamination grade steel
  • Three year warranty.
208V AMPS: 81.1
BEARING-DRIVE-END: 6311
BEARING-OPP-DRIVE-END: 6309
CUSTOMER-PART-NUMBER: --
DESIGN CODE: B
DOE-CODE: 010A
FL EFFICIENCY: 94.1
ENCLOSURE: OPSB
FRAME: 286T
GREASE: POLYREX EM
HERTZ: 60
CATALOG NUMBER: EM2535T-8
SPEC. NUMBER: 40G048W947
INSULATION-CLASS: F
KVA-CODE: G
MAX. SPACE HEATER TEMP.: --
SPEED [rpm]: 1770
OUTPUT [hp]: 30
PHASE: 3
POWER-FACTOR: 85
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
SPACE-HEATER-AMPS: --
SPACE-HEATER-VOLTS: --
VOLTAGE: 200
FL AMPS: 81
30HP BALDOR 1770RPM 286T OPSB 200V 3PH MOTOR EM2535T-8
Click Image to Enlarge
Manufacturer Part Number: EM2535T-8
Stock # EM2535T-8
Price: $1,872.00
Compare At: $3,462.00
