40HP BALDOR 1775RPM 324JM TEFC 3PH MOTOR EJMM4110T

Catalog Number:  EJMM4110T
Description:  40HP,1775RPM,324JM,TEFC,3PH,60HZ,SUPER-E
Ship Weight:  586 lbs.

APPLICATIONS:  Designed for operations where continuous or frequent duty is required. Usable for a wide variety of applications for circulating and transferring fluids. Mounting designed to support pump unit. Super-E motors are designed to conserve energy over extended time periods.

FEATURES:

  • Super-E Premium Efficient Motor
  • Heavy gauge steel frames
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Over-sized ball bearings with locked drive end construction to minimize endplay
  • Low-loss electrical grade lamination steel
  • Three year warranty
208V AMPS: 102
BEARING-DRIVE-END: 6312
BEARING-OPP-DRIVE-END: 6311
CUSTOMER-PART-NUMBER: --
DESIGN CODE: B
DOE-CODE: 010A
FL EFFICIENCY: 94.1
ENCLOSURE: TEFC
FRAME: 324JM
GREASE: POLYREX EM
HERTZ: 60
CATALOG NUMBER: EJMM4110T
SPEC. NUMBER: 12J043Y276G1
INSULATION-CLASS: F
KVA-CODE: H
MAX. SPACE HEATER TEMP.: --
SPEED [rpm]: 1775
OUTPUT [hp]: 40
PHASE: 3
POWER-FACTOR: 82
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
SPACE-HEATER-AMPS: --
SPACE-HEATER-VOLTS: --
VOLTAGE: 230/460
FL AMPS: 96/48
40HP BALDOR 1775RPM 324JM TEFC 3PH MOTOR EJMM4110T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: EJMM4110T
Stock # EJMM4110T
Price: $3,635.00
Compare At: $6,725.00
