50HP BALDOR 3530RPM 324JM OPSB 3PH MOTOR EJMM2542T

Catalog Number:  EJMM2542T
Description:  50HP,3530RPM,324JM,OPSB,3PH,60HZ,SUPER-E
Ship Weight:  421 lbs.

APPLICATIONS:  Designed for operations where continuous or frequent duty is required. Usable for a wide variety of applications for circulating and transferring fluids. Mounting designed to support pump unit. Super-E motors are designed to conserve energy over extended time periods.

FEATURES:

  • Super-E Premium Efficient Motor
  • Heavy gauge steel frames
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Over-sized ball bearings with locked drive end construction to minimize endplay
  • Low-loss electrical grade lamination steel
  • Open drip-proof, close coupled pump motors are furnished with rodent screens at both ends
  • Three year warranty
208V AMPS:  --
BEARING-DRIVE-END:  6312
BEARING-OPP-DRIVE-END:  6309
CUSTOMER-PART-NUMBER:  --
DESIGN CODE:  B
DOE-CODE:  010A
FL EFFICIENCY:  94.1
ENCLOSURE:  OPSB
FRAME:  324JM
GREASE:  POLYREX EM
HERTZ:  60
CATALOG NUMBER:  EJMM2542T
SPEC. NUMBER:  40E214W576
INSULATION-CLASS:  F
KVA-CODE:  H
MAX. SPACE HEATER TEMP.:  --
SPEED [rpm]:  3530
OUTPUT [hp]:  50
PHASE:  3
POWER-FACTOR:  90
RATING:  40C AMB-CONT
SERIAL-NUMBER:  --
SERVICE FACTOR:  1.15
SPACE-HEATER-AMPS:  --
SPACE-HEATER-VOLTS:  --
VOLTAGE:  208-230/460
FL AMPS:  122-110/55



50HP BALDOR 3530RPM 324JM OPSB 3PH MOTOR EJMM2542T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: EJMM2542T
Stock # EJMM2542T
Price: $3,112.00
Compare At: $5,710.00
