200HP BALDOR 1190RPM 449T TEFC 3PH MOTOR ECP44206T-4

Catalog Number:  ECP44206T-4
Description:  200HP,1190RPM,449T,TEFC,3PH,60HZ,CHEM DUTY,PREMIUM
Ship Weight:  3120 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS: Petro-chemical plants, mines, foundries, pulp and paper plants, waste management facilities, chemical plants, tropical climates and other processing industry applications requiring protection against corrosion caused by severe environmental operating conditions.

FEATURES:

  • 1.15 Service Factor
  • Corrosion resistant epoxy finish
  • Regreasable ball or roller bearings
  • Oversized rotatable cast iron conduit box
  • Cast iron frames
  • Forsheda® shaft seal
  • Moisture resistant copper windings
  • Class F insulation
  • Tropicalization
  • Stainless steel nameplate and corrosion resistant hardware
  • 3 year warranty
FL AMPS: 225
BEARING-DRIVE-END: 6318
BEARING-OPP-DRIVE-END: 6318
BRG-DE-AFBMA: 90BC03J30X
BRG-ODE-AFBMA: 90BC03J30X
DESIGN CODE: B
DUTY: CONT
FL EFFICIENCY: 95.8
EFFICIENCY-1: 96.1
EFFICIENCY-2: 95.0
EFFICIENCY-3: --
ENCLOSURE: TEFC
CATALOG NUMBER: ECP44206T-4
SPEC. NUMBER: P44G5288
AMBIENT-TEMPERATURE: 40
HERTZ: 60
HORSEPOWER: 200
INSULATION CLASS: F
KVA-CODE: G
SPEED [rpm]: 1190
MOTOR-WEIGHT: --
PHASE: 3
POWER-FACTOR: 86.7
POWER-FACTOR-CORRECTION CAPAC: 35.0
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
TYPE: P
VOLTAGE: 460
FRAME: 449T
200HP BALDOR 1190RPM 449T TEFC 3PH MOTOR ECP44206T-4
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: ECP44206T-4
Stock # ECP44206T-4
Price: $17,757.00
Compare At: $31,553.00
