300HP BALDOR 1150RPM 4013ATZ DPG-FV 500VDC MOTOR D51300R-BV

Catalog Number:  D51300R-BV
Description:  300HP,1150/2000RPM,DPG-FV,LC4013ATZ,500VDC,SHUNT WOUND
Ship Weight:  3015 lbs.

APPLICATIONS: Designed for use with metals, printing, extruders, cranes, conveyors, machine tools.

FEATURES:

  • Field amps at 25*C
  • Laminated square frame for improved commutation
  • Tach adaptable with thermostat
Catalog Number: D51300R-BV
Specification Number: T40S1320
Horsepower: 300
Armature Voltage: 500
Field Voltage: 300
Full Load Amps - Armature: 485.00
Full Load Amps - Field: 13.20
RPM: 1150
Frame Size: LC 4013ATZ
Service Factor: 1.0
Rating: N/A
Insulation Class: F
Form Factor: N/A
Enclosure: DPFV
Baldor Type: N/A
DE Bearing: 95BC02J30X
ODE Bearing: 95BC02J30X
Electrical Specification Number: N/A
Mechanical Specification Number: N/A
Base: N/A
Mounting: F2
Tach Mounting Kit: N/A
Blower Kit: N/A
Filter Kit: N/A
Recommended SCR Control: N/A
Brush Part Number: 419904-52AA
300HP BALDOR 1150RPM 4013ATZ DPG-FV 500VDC MOTOR D51300R-BV
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: D51300R-BV
Stock # D51300R-BV
Price: $86,272.00
Compare At: $163,196.00
