150HP BALDOR 1750RPM 407-9AT 500VDC MOTOR D50150P-BV

150HP BALDOR 1750RPM 407-9AT 500VDC MOTOR D50150P-BV

Picture is for reference only.

Part Number:

D50150P-BV

Model/Spec Number:

T40R8003

Manufacturer:

Baldor Obsolete Motors

Manufacturer Part Number:

D50150P-BV
BALDOR D50150P-BV 150HP DC DPBV Shunt Stabilized and Shunt Wound Motor is designed for use with conveyors, plastic extruders, packaging machinery and other constant torque applications for DC SCR motors.

Item Discontinued

Click below to view suggested functional replacement.
See Replacement Item

Free No Rush Shipping

Weight:

1,460 lbs

Dimensions:

14 x 26 x 14 inches

HS Code:

8501534080

UPC:

781568136164

Technical Details

Application:

General Purpose

Output HP:

150

Frame NEMA:

407-09AT

Mount NEMA:

With Base

Input Voltage DC:

500

Full Load Amps:

238

Field Voltage:

150/300

Winding:

Shunt Wound

Enclosure NEMA:

DPBV

Brand:

Baldor

Product Information Packet

APPLICATIONS: Designed for use with conveyors, plastic extruders, packaging machinery and other constant torque applications for DC SCR motors.

FEATURES:

  • High dielectric stability
  • Low moment of inertia armature for fast response
  • Includes thermostat on interpole
  • Constant pressure brush springs and longer brushes for reduced maintenance
  • Class F insulation system
  • Includes grease fittings and reliefs for bearing maintenance
  • Tachometer adaptable
  • Blower-ventilated, includes filter
