75HP BALDOR 1780RPM 365TC TEFC 3PH MOTOR CEM4316T

Catalog Number:  CEM4316T
Description:  75HP,1780RPM,365TC,TEFC,3PH,60HZ,SUPER-E
Ship Weight:  977 lbs.

APPLICATIONS: Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Heavy gauge steel and cast iron frames
  • 2 3/8" keyed output shaft
  • Ball bearings
  • ISR® (Inverter Spike Resistant®) copper windings
  • Low-loss electrical grade lamination steel
  • Three year warranty
AG-BLANK-LINE-1A: SUIT FOR 208V @ 187 AMPS
AG-BLANK-LINE-1B: --
AG-BLANK-LINE-2A: --
AG-BLANK-LINE-2B: --
AMBIENT-TEMPERATURE: 40
FL AMPS: 171/85.9
BRG-DE-AFBMA: 65BC03J30X
BRG-ODE-AFBMA: 65BC03J30X
DESIGN CODE: B
DUTY: CONT
FL EFFICIENCY: 95.4
ENCLOSURE: TEFC
CATALOG NUMBER: CEM4316T
FRAME: 365TC
HERTZ: 60
INSULATION CLASS: F
KVA-CODE: G
SPEED [rpm]: 1780
MOTOR-WEIGHT: --
OUTPUT [hp]: 75
PHASE: 3
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
SPEC. NUMBER: P36G4664
TYPE: P
VOLTAGE: 230/460
75HP BALDOR 1780RPM 365TC TEFC 3PH MOTOR CEM4316T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: CEM4316T
Stock # CEM4316T
Price: $6,162.00
Compare At: $11,400.00
