75HP BALDOR 3555RPM 365TSC TEFC 3PH MOTOR CEM4313T

Catalog Number:  CEM4313T
Spec Number:  P36G4677
Description:  75HP,3555RPM,365TSC,TEFC,3PH,60HZ,SUPER-E
Ship Weight:  804 lbs.

APPLICATIONS: Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Heavy cast iron frame
  • 1 7/8" keyed output shaft 1.875"
  • Ball bearings
  • ISR® (Inverter Spike Resistant®) copper windings
  • Low-loss electrical grade lamination steel
  • Three year warranty
AG-BLANK-LINE-2A: --
AG-BLANK-LINE-3A: --
AMBIENT-TEMPERATURE: 40
FL AMPS: 167/83.4
BRG-DE-AFBMA: 65BC03J30X
BRG-ODE-AFBMA: 65BC03J30X
DESIGN CODE: B
DUTY: CONT
FL EFFICIENCY: 93.6
EFFICIENCY-2: 92.4
EFFICIENCY-3: --
ENCLOSURE: TEFC
CATALOG NUMBER: CEM4313T
SPEC. NUMBER: P36G4677
AG-BLANK-LINE-1A: --
HERTZ: 60
INSULATION CLASS: F
KVA-CODE: E
MAX. KVAR: 09.5
SPEED [rpm]: 3555
MOTOR-WEIGHT: --
OUTPUT [hp]: 75
PHASE: 3
POWER-FACTOR: 90
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
TYPE: P
VOLTAGE: 230/460
FRAME: 365TSC
75HP BALDOR 3555RPM 365TSC TEFC 3PH MOTOR CEM4313T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: CEM4313T
Stock # CEM4313T
Price: $6,204.00
Compare At: $11,478.00
