60HP BALDOR 3550RPM 364TSC TEFC 3PH MOTOR CEM4310T

Catalog Number:  CEM4310T
Description:  60HP,3550RPM,364TSC,TEFC,3PH,60HZ,SUPER-E
Ship Weight:  830 lbs.

APPLICATIONS: Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Heavy gauge steel and cast iron frames
  • 2 3/8" keyed output shaft
  • Ball bearings
  • ISR® (Inverter Spike Resistant®) copper windings
  • Low-loss electrical grade lamination steel
  • Three year warranty
AG-BLANK-LINE-2A: --
AG-BLANK-LINE-3A: --
AMBIENT-TEMPERATURE: 40
FL AMPS: 135/67.3
BRG-DE-AFBMA: 65BC03J30X
BRG-ODE-AFBMA: 65BC03J30X
DESIGN CODE: B
DUTY: CONT
FL EFFICIENCY: 93.6
EFFICIENCY-2: 92.4
EFFICIENCY-3: --
ENCLOSURE: TEFC
CATALOG NUMBER: CEM4310T
SPEC. NUMBER: P36G4676
AG-BLANK-LINE-1A: --
HERTZ: 60
INSULATION CLASS: F
KVA-CODE: F
MAX. KVAR: 08.7
SPEED [rpm]: 3560
MOTOR-WEIGHT: --
OUTPUT [hp]: 60
PHASE: 3
POWER-FACTOR: 89
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
TYPE: P
VOLTAGE: 230/460
FRAME: 364TSC
60HP BALDOR 3550RPM 364TSC TEFC 3PH MOTOR CEM4310T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: CEM4310T
Stock # CEM4310T
Price: $5,407.00
Compare At: $10,003.00
