50HP BALDOR 1775RPM 326TC TEFC 3PH MOTOR CEM4115T

Catalog Number:  CEM4115T
Spec Number:  12C052X278G1
Description:  50HP,1775RPM,326TC,TEFC,3PH,60HZ,SUPER-E
Ship Weight:  585 lbs.

APPLICATIONS: Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Class F insulated, 1.15 service factor. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • Heavy gauge steel and cast iron frames
  • 2 1/8" keyed output shaft
  • Ball bearings
  • ISR® (Inverter Spike Resistant®) copper windings
  • Low-loss electrical grade lamination steel
  • Three year warranty
208V AMPS: 122
BEARING-DRIVE-END: 6312
BEARING-OPP-DRIVE-END: 6311
CUSTOMER-PART-NUMBER: --
DESIGN CODE: B
DOE-CODE: 010A
FL EFFICIENCY: 94.5
ENCLOSURE: TEFC
FRAME: 326TC
GREASE: POLYREX EM
CATALOG NUMBER: CEM4115T
SPEC. NUMBER: 12C052X278G1
FL AMPS: 114/57
INSULATION-CLASS: F
KVA-CODE: H
SPEED [rpm]: 1775
OUTPUT [hp]: 50
PHASE: 3
POWER-FACTOR: 87
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
SPACE-HEATER-AMPS: --
SPACE-HEATER-VOLTS: --
VOLTAGE: 230/460
HERTZ: 60
50HP BALDOR 1775RPM 326TC TEFC 3PH MOTOR CEM4115T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: CEM4115T
Stock # CEM4115T
Price: $3,833.00
Compare At: $7,092.00
