7.5HP BALDOR 1770RPM 213TC OPSB 3PH MOTOR CEM3311T

Catalog Number:  CEM3311T
Spec Number:  37B102S520G1
Description:  7.5HP,1770RPM,213TC,OPSB,3PH,60HZ,SUPER-E
Ship Weight:  114 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS: Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • 36 Month warranty
  • 1-3/8" Keyed output shaft
  • Heavy duty frames
  • Ball bearings
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Low-loss electrical lamination grade steel
SPEC. NUMBER: 37B102S520G1
CATALOG NUMBER: CEM3311T
FL AMPS: 19.4/9.7
208V AMPS: 20.4
BEARING-DRIVE-END: 6307
BEARING-OPP-DRIVE-END: 6206
DESIGN CODE: A
DOE-CODE: 010A
FL EFFICIENCY: 91
ENCLOSURE: OPSB
FRAME: 213TC
HERTZ: 60
INSULATION-CLASS: F
KVA-CODE: J
SPEED [rpm]: 1770
OUTPUT [hp]: 7.5
PHASE: 3
POWER-FACTOR: 79
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
VOLTAGE: 230/460
7.5HP BALDOR 1770RPM 213TC OPSB 3PH MOTOR CEM3311T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: CEM3311T
Stock # CEM3311T
Price: $834.00
Compare At: $1,543.00
