100HP BALDOR 1780RPM 404TC OPSB 3PH MOTOR CEM2555T

Catalog Number:	CEM2555T
Description:	100HP,1780RPM,404TC,OPSB,3PH,60HZ,SUPER-E
Ship Weight:	945 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS: Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

36 Month warranty
Heavy duty frames
Ball bearings
Moisture resistant ISR® (Inverter Spike Resistant) copper windings
Low-loss electrical lamination grade steel

208V AMPS:	--
BEARING-DRIVE-END:	6316
BEARING-OPP-DRIVE-END:	6312
CUSTOMER-PART-NUMBER:	--
DESIGN CODE:	A
DOE-CODE:	010A
FL EFFICIENCY:	95.4
ENCLOSURE:	OPSB
FRAME:	404TC
GREASE:	POLYREX EM
HERTZ:	60
CATALOG NUMBER:	CEM2555T
SPEC. NUMBER:	44E013W308G1
INSULATION-CLASS:	F
KVA-CODE:	H
MAX. SPACE HEATER TEMP.:	--
SPEED [rpm]:	1780
OUTPUT [hp]:	100
PHASE:	3
POWER-FACTOR:	83
RATING:	40C AMB-CONT
SERIAL-NUMBER:	--
SERVICE FACTOR:	1.15
SPACE-HEATER-AMPS:	--
SPACE-HEATER-VOLTS:	--
VOLTAGE:	230/460
FL AMPS:	236/118
