40HP BALDOR 1775RPM 324TC OPSB 3PH MOTOR CEM2539T

Catalog Number:  CEM2539T
Description:  40HP,1775RPM,324TC,OPSB,3PH,60HZ,SUPER-E
Ship Weight:  460 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS: Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • 36 Month warranty
  • Heavy duty frames
  • Ball bearings
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Low-loss electrical lamination grade steel
208V AMPS: 101
BEARING-DRIVE-END: 6312
BEARING-OPP-DRIVE-END: 6311
CUSTOMER-PART-NUMBER: --
DESIGN CODE: B
DOE-CODE: 010A
FL EFFICIENCY: 94.1
ENCLOSURE: OPSB
FRAME: 324TC
GREASE: POLYREX EM
HERTZ: 60
CATALOG NUMBER: CEM2539T
SPEC. NUMBER: 42D102W505G1
INSULATION-CLASS: F
KVA-CODE: F
MAX. SPACE HEATER TEMP.: --
SPEED [rpm]: 1775
OUTPUT [hp]: 40
PHASE: 3
POWER-FACTOR: 85
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
SPACE-HEATER-AMPS: --
SPACE-HEATER-VOLTS: --
VOLTAGE: 230/460
FL AMPS: 94/47
40HP BALDOR 1775RPM 324TC OPSB 3PH MOTOR CEM2539T
Click Image to Enlarge
Image for quick reference only
Manufacturer Part Number: CEM2539T
Stock # CEM2539T
Price: $2,878.00
Compare At: $5,325.00
