20HP BALDOR 1765RPM 256TC OPSB 3PH SUPER-E MOTOR CEM2515T

20HP BALDOR 1765RPM 256TC OPSB 3PH SUPER-E MOTOR CEM2515T

Picture is for reference only.

Part Number:

CEM2515T

Model/Spec Number:

39D102X952G1

Manufacturer:

ABB/Baldor
CEM2515T BALDOR 20HP Three Phase Electric Motor is designed for pumps, fans, compressors, blowers, machine tools, conveyors and many other applications. Super-E Motors are designed to conserve energy over extended time periods.
MSRP: $4,812.00

Regular Price

USD

$

3,458

22

QTY
Login to View Discounts

Free No Rush Shipping

Weight:

231 lbs

Dimensions:

22 x 31 x 19 inches

HS Code:

8501.52.4000

UPC:

781568541128

Technical Details

Brand:

Baldor

Application:

General Purpose

Output HP:

20

Output KW:

15

Output RPM:

1765

Frame Size NEMA:

256TC

Mount NEMA:

C Face With Base

Enclosure NEMA:

OPSB

Enclosure IEC:

IP22

Voltage:

230/460//190/380

CEM2515T-InfoPacket

APPLICATIONS: Typical applications include pumps, fans, compressors, blowers, industrial machines, conveyors and other general purpose applications. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2.

FEATURES:

  • Heavy duty frame
  • 1 5/8" Keyed output shaft
  • Optimized airflow design providing higher horsepower in a smaller package
