15HP BALDOR 1765RPM 254TC OPSB 3PH MOTOR CEM2513T

Catalog Number:  CEM2513T
Spec Number:  39D102W916G2
Description:  15HP,1765RPM,254TC,OPSB,3PH,60HZ,SUPER-E
Ship Weight:  213 lbs.

This Baldor Motor Can Only Ship Ground Freight
For expedited needs please contact our sales team.

APPLICATIONS: Typical applications include operations where continuous or frequent duty is required. Super-E Motors are designed to conserve energy over extended time periods. Inverter rated per NEMA MG1 Part 31.4.4.2. Suitable for variable torque applications and 20:1 constant torque speed range with properly sized and adjusted variable frequency drives.

FEATURES:

  • 36 Month warranty
  • 1-5/8" Keyed output shaft
  • Heavy duty frame
  • Ball bearings
  • Moisture resistant ISR® (Inverter Spike Resistant) copper windings
  • Low-loss electrical lamination grade steel
SPEC. NUMBER: 39D102W916G2
CATALOG NUMBER: CEM2513T
FL AMPS: 37.4-35.4/17.7
208V AMPS: 37.4
BEARING-DRIVE-END: 6309
BEARING-OPP-DRIVE-END: 6208
DESIGN CODE: B
DOE-CODE: 010A
FL EFFICIENCY: 93
ENCLOSURE: OPSB
FRAME: 254TC
HERTZ: 60
INSULATION-CLASS: F
KVA-CODE: G
SPEED [rpm]: 1765
OUTPUT [hp]: 15
PHASE: 3
POWER-FACTOR: 86
RATING: 40C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.15
VOLTAGE: 208-230/460
15HP BALDOR 1765RPM 254TC OPSB 3PH MOTOR CEM2513T
Click Image to Enlarge
Picture is for quick reference only
Manufacturer Part Number: CEM2513T
Stock # CEM2513T
Price: $1,455.00
Compare At: $2,692.00
