7.5HP BALDOR 1760RPM 254U TEFC 3PH MOTOR AEM2237-4

Catalog Number:  AEM2237-4
Description:  7.5HP,1760RPM,254U,TEFC,3PH,60HZ,AUTOMOTIVE
Ship Weight:  224 lbs.

APPLICATIONS: Designed for use in plants requiring Automotive Approved Motors on pumps, compressors, fans, conveyors, machine tools and other applications.

FEATURES:

  • Approved by major US automobile manufacturers
  • Meets efficiency times power factor requirements per GM7EQ
  • All cast iron construction
  • Regreasable double shield ball bearings
  • Shaft slinger on both ends of motor
  • Stainless steel nameplate
  • Epoxy paint
  • Suitable for 65ºC ambient 1.00 Service Factor or 1.15 Service Factor, 40ºC ambient
  • Meets automotive requirements for sound levels
  • Meets GM for minimum efficiency times power factor requirements per GM7EHQ
BEARING-DRIVE-END: 6309
BEARING-OPP-DRIVE-END: 6208
DESIGN CODE: B
DOE-CODE: --
FL EFFICIENCY: 87.5
FL EFFICIENCY: 89.5
ENCLOSURE: TEFC
FRAME: 254U
GREASE: POLYREX EM
CATALOG NUMBER: AEM2237-4
SPEC. NUMBER: 09T36X153M
HERTZ: 60
INSULATION-CLASS: F
KVA-CODE: G
SPEED [rpm]: 1760
OUTPUT [hp]: 7.50
PHASE: 3
POWER-FACTOR: 84
RATING: 65C AMB-CONT
SERIAL-NUMBER: --
SERVICE FACTOR: 1.00
VOLTAGE: 460
FL AMPS: 9.2
7.5HP BALDOR 1760RPM 254U TEFC 3PH MOTOR AEM2237-4
Click Image to Enlarge
Manufacturer Part Number: AEM2237-4
Stock # AEM2237-4
Price: $1,930.00
Compare At: $3,322.00
